Meddle Pressure Automatic Spray Gun

KL-110 KL-210



KL-110/210

Characteristics:
Wide spray pattern range, very fine atomizing particle, even spread, fast coating material flow, steady, highly effective spray and save the coating material
Special air cap design with a simple maintenance is not easy to remain the coating material.
Spray nozzle and needle are made by SUS303 stainless steel and allow spraying the water basis coating material.
The Teflon seal ring is used to hold tightly the spray needle and could resist chemical solvent, acid, alkali…etc.





KL-110
Spraying distance 200mm; Fluid Viscosity 9 sec/NK-2;
Paint Pressure 0.08MPa(0.8bar/11PSI); Fluid Inlet 1/4PF; Air Inlet 1/4PF;
Cylinder Inlet 1/4PF

KL-210
Spraying distance 200mm; Fluid Viscosity 9 sec/NK-2;
Paint Pressure 0.08MPa(0.8bar/11PSI); Fluid Inlet 3/8PF; Air Inlet 1/4PF;
Cylinder Inlet 1/4PF
