FEATURE:

■ PLC control for easy operation and control
■ For strip shape object, one-time quick spray for above side and two counter sides
■ Inductor controls all of the spray guns saving lots spray materials during operation.
■ Two dust-collect trays could collect unused spray materials for re-use.
■ Powerful wind-collector filter can purify the air.
■ Omni sealed cabinet can create no-pollution working environments.
■ Extra spray guns are options

Max. Working Width------------------------------------------------------------------------------300mm
Max. Working Thickness -------------------------------------------------------------------------90mm
Max. Working Length ----------------------------------------------------------------------------- infinite
Min. Working Length -----------------------------------------------------------------------------550mm
Feed Speed (Variable)---------------------------------------------------------------- 10M~30M/min
Painting Pump -----------------------------------------------------------------------------------17P0201
Air Spraying Guns ------------------------------------------------------------------------------------4pcs
Exhaust Fan Motor ------------------------------------------------------------------------------------3HP
Size of Machine (LxWxH) mm -----------------------------------350(L)x1550(W)x2500(H)mm
Weight ------------------------------------------------------------------------------------------------1453kg
