FEATURE:

■ PLC control design with intelligent human interface for easy operation, program
　upgrade or production procedure modification.
■ Automatic cleaning system for cleaning spray gun, hose, and paint tank.
　Can Saves valuable labor time.
■ Powerful patented paint and dust collection system ensures maximum collection of
　unused spray materials for re-use.
■ Powerful wind-collector filter ensures proper air purification.
■ All the spray guns are controlled by the inductor, thus saving a significant amount of
　spraying materials during operation.
■ Sensor controlled automatic door with omni cabinet creates a pollution free working
　environment.
■ Auto-turned spray booth holder can spray 5 sides with 4 spray guns in one procedure.
■ Working product quantity could be calculated and programmed accordingly.
■ Standard Machine equipped with 4pcs spray guns.      Optional: 2pcs spray guns

Specifications:

Max. Working Width-----------------------------------------------------------------------------------660mm
Max. Working Height----------------------------------------------------------------------------------300mm
Min. Working Size------------------------------------------------------50mm(L)x50mm(W)x25mm(H)
Painting Pump----------------------------------------------------------------------------------------17P0201
Air Spraying Guns----------------------------------------------------------------------------------------4PCS
Air Consumption---------------------------------------------------------------------------------0.4~0.6MPA
Size of Machine (LxWxH) mm -------------------------------------2250(L)x1500(W)x2000(H)mm
Weight-------------------------------------------------------------------------------------------------------600kg
