FEATURES:
Designed to meet strict coating requirements.
It accommodates a wide variety of wood coating materials.
Extremely efficient spraying performance.
It reduces environmental contamination problems, meeting environmental protection requirements.
It creates a super fine finish on painted surfaces, reducing the polishing processes suited for high production lines.

STANDARD EQUIPMENT:
● Bell unit
● High voltage power supply
● Paint pump unit
● Controller
● Reciprocator

OPTIONAL EQUIPMENT:
● Compressor
● Air dryer

SPECIFICATION:
BELL UNIT
● Bell diameter- 75mm
● Atomizing capacity- Max. 300cc/min
● Motor- Air bearing turbo motor
● Bell speed- Max. 20000 RPM

HIGH VOLTAGE POWER SUPPLY
● Power required...100VACO 10% 50/60Hz, 150VA
● High voltage output...30KV to -90KV, 300 Micro Amp. (Max)

PAINT PUMP
● Explosion- proof motor, 0.4KW
● Discharge rate- 300cc/min. (Max.)

RECIPROCATOR
● Power- 1KW
● Drive method- AC Motor
● Speed- 5 to 36 m/min., variable

CONTROLLER
● Turbo bell RPM controller
● High voltage controller
● Speed control
